Aluminum Electrolytic Capacitors
Aluminum Electrolytic Capacitors
>
>
>
>
>
>
CMB0G471M0607
CMB0G471M0607
Specifications
Specifications
Type
Solid
Type
Solid
Capacitance
470 µF
Capacitance
470 µF
Capacitance Tolerance
-20%~20%
Capacitance Tolerance
-20%~20%
tanδ
0.12
tanδ
0.12
Rated Voltage
4 V
Rated Voltage
4 V
Leakage Current
376 µA
Leakage Current
376 µA
Rated ripple current
376 mA rms
Rated ripple current
376 mA rms
Temperature Range
Temperature Range
Diameter
6.3 mm
Diameter
6.3 mm
Length
7.7 mm
Length
7.7 mm
Life/Endurance
Life/Endurance
MPQ
1000 pcs/reel
MPQ
1000 pcs/reel
